AVENTICS 二位三通換向閥，電氣操作 R412009388

產品描述

AS5-SOV-G100-3/2-POS-024-PN-K03U

技術規格

操作電子

額定流量Qn12500 l/min

壓縮空氣連接G 1

最小運行壓力2.5 bar

最大運行壓力10 bar

工作電壓DC24 V

密封原理軟密封

組成部分二位三通換向閥

可以組裝成塊可以組裝成塊

帶有導線盒的基礎閥門帶有先導閥的基礎閥

結構特點提動閥

最低環境溫度-10 °C

最高環境溫度50 °C

介質壓縮空氣, 中性氣體

顆粒大小 max.25 μm

壓縮空氣連接 排氣G 1/2

額定流量Qn 1 向 212500 l/min

額定流量 Qn 2 向 33700 l/min

工作電壓24 V DC

功率 消耗 DC2 W

帶接口的防護等級IP65

電子接口型號 2多芯插頭

電氣連接 2, 螺紋尺寸ISO 15217, C 型

電氣連接 傳感器線芯外露部分鍍錫

電纜長度3 m
