AVENTICS短行程氣缸R412019876 SSI-DA-080-0025-4-02-2-000-000-00

產品規格：

標準ISO 15524

活塞- ?80 mm

行程25 mm

實用原則雙作用式

緩沖elastické tlumení

磁性銷釘Píst s magnetem

環境要求工業標準

活塞桿單的

防塵圈標準工業防塵刮環

確定活塞推力的壓力6,3 bar

縮回運動的活塞力2857 N

伸出運動的活塞力3167 N

最低環境溫度-20 °C

最高環境溫度80 °C

最小運行壓力0.6 bar

最大運行壓力10 bar

接口G 3/8

活塞桿螺紋M16

沖撞能量0.43 J

重量 0 mm行程1.09 kg

重量 +10 mm行程0.122 kg

最大行程150 mm

介質壓縮空氣

介質溫度最小值-20 °C

介質溫度最大值80 °C

R404069378 SSI-DA-080-0020-9-00-2-SPEC.COVER-WH=20

R404069419 SSI-DA-080-0003-4-02-2-B015-A120

R404069936 SSI-DA-080-0025-B015-A006

R404070160 SSI-DA-080-0025-9-02-2-A120

R404072477 SSI-DA-080-0050-4-02-2-B015

R404073189 SSI-DA-080-0040-4-02-2-B015-A120

R412019872 SSI-DA-080-0005-4-02-2-000-000-00

R412019873 SSI-DA-080-0010-4-02-2-000-000-00

R412019874 SSI-DA-080-0015-4-02-2-000-000-00

R412019875 SSI-DA-080-0020-4-02-2-000-000-00

R412019876 SSI-DA-080-0025-4-02-2-000-000-00

R412019877 SSI-DA-080-0030-4-02-2-000-000-00

R412019878 SSI-DA-080-0040-4-02-2-000-000-00

R412019879 SSI-DA-080-0050-4-02-2-000-000-00

R412019880 SSI-DA-080-0080-4-02-2-000-000-00

R412019968 SSI-DA-080-0025-4-03-2-000-000-00

R412019969 SSI-DA-080-0030-4-03-2-000-000-00

R414010076 SSI-DA-080-0040-MD-TH-IT-MODI

R480637893 SSI-DA-080-0005-9-02-2-000-000-00

R480637894 SSI-DA-080-0010-9-02-2-000-000-00

R480637895 SSI-DA-080-0015-9-02-2-000-000-00

R480637896 SSI-DA-080-0020-9-02-2-000-000-00

R480637897 SSI-DA-080-0025-9-02-2-000-000-00

R480637898 SSI-DA-080-0030-9-02-2-000-000-00

R480637899 SSI-DA-080-0040-9-02-2-000-000-00

R480637900 SSI-DA-080-0050-9-02-2-000-000-00

R480637901 SSI-DA-080-0080-9-02-2-000-000-00

R480643564 SSI-DA-080-0015-4-00-2-000-000-00

R480643565 SSI-DA-080-0025-4-00-2-000-000-00

R480644577 SSI-DA-080-0030-4-00-2-000-000-00

R480645384 SSI-DA-080-0035-9-02-2-000-000-00

R480645526 SSI-DA-080-0050-9-00-2-000-000-00

R480645766 SSI-DA-080-0025-9-00-2-000-000-00

R480646920 SSI-DA-080-0080-9-00-2-000-000-00

R480651581 SSI-DA-080-0060-9-02-2-000-000-00

R480655569 SSI-DA-080-0020-4-00-2-000-R06-02

R480656799 SSI-DA-080-0070-4-00-2-000-000-00

R480659836 SSI-DA-080-0035-4-03-2-000-000-00

R480660336 SSI-DA-080-0035-4-00-2-000-000-00

R480661434 SSI-DA-080-0030-4-00-4-035-000-00

R480664773 SSI-DA-080-0060-4-02-2-000-R06-16

R480665365 SSI-DA-080-0050-9-02-4-010-000-00

R480669126 SSI-DA-080-0050-4-02-2-000-I08-16

R480673195 SSI-DA-080-0075-4-03-2-000-000-00

R480673197 SSI-DA-080-0045-4-03-2-000-000-00
